Product Parameter:
| Item | Parameter | Remark |
| Energy | 4.8KWh | |
| Rated Capacity | 100Ah | At 23℃±5℃, after standard charged, 0.33C constant current discharging, 37.5V cut off |
| Min. Capacity | 100Ah | At 23℃±5℃, after standard charged, 0.33C constant current discharging, 37.5V cut off |
| Rated Voltage | 48V | Battery module rated voltage |
| Standard Charge Current | 50A(0.5C) | 0℃~45℃，0.5C CC（Constant current）charge to 54.8V, then CV（constant voltage）charge. |
| Max Charge Current | 100A(1C) | 0℃~45℃，do not exceed 1C |
| Charge Cut Off Voltage | 54.8V | |
| Standard Discharge Current | 50A(0.5C) | -20℃~ +60℃，0.5C CC(Constant Current) discharge, cut off @37.5V. |
| Max Continuous Discharge Current | 100A | 25℃±3℃，continuous 100A discharge |
| Discharge Cut Off Voltage | 37.5V | |
| Max Pulse Discharge Current | 105A | 25℃±3℃；≤1S |
| WorkingTemperature (charge) | 0℃~45℃ | Duringcharge, battery and ambienttemperature should not exceed 45℃. |
| Working Temperature (discharge) | -20℃~55℃ | Battery can work at specified temperature range with capacity loss in tolerance. |
| Storage Temperature | -20℃~45℃ | (short term) Within 1 month |
| -10℃~35℃ | (long term) Within 1 year | |
| Life Cycle Character | ≥6000 Cycles | After finish the standard charging,lay aside for 30
min, in 25±5℃，0.33C constant current discharge to 80%DOD, then go for next cycle. |
| Battery Weight | 42Kg | |
| Battery Impedance | ≤65mΩ | AC 1KHz impedance with half electricity |
